Product Overview
The Hikvision DS‑3WR3N is an entry-level Wi-Fi 4 (802.11n) 2.4 GHz wireless router that offers up to 300 Mbps data rates, designed for basic home and small office use. With dual external high-gain antennas and beamforming technology, it delivers reliable connectivity for internet browsing, email, video streaming, and light online gaming across compact environments.
This compact tabletop router also supports flexible operating modes, including Router, Repeater, Client + AP, WISP, and Access Point, making it suitable for tailored applications like boosting weak Wi‑Fi signals or sharing ISP access wirelessly.
Signal & Coverage
Equipped with two external 5 dBi high-gain antennas, the DS‑3WR3N extends wireless range and reduces dead zones. With built-in beamforming support, it intelligently directs signals toward connected devices—enhancing stability and performance in congested or larger indoor spaces.
Ports & Physical Features
The router provides reliable wired connections with 4 fast Ethernet ports: one 10/100 Mbps WAN input and three 10/100 Mbps LAN outputs. A reset/WPS button allows for easy setup or restoration of default settings. LED indicators display system status, WLAN, LAN, and WAN activity. Power is supplied via a 9 V DC, 0.6–1 A adapter, consuming under 5–6 W.
Modes, Security & Management
Supports multiple modes: Router, Repeater, Client+AP, WISP, AP
Security includes WPA‑PSK / WPA2‑PSK, hidden SSID, scheduled access, and system logs. Built-in DHCP server simplifies IP assignment for connected devices.
Managed via a user-friendly web UI, accessible through default addressing like
hikvisionwifi.local, including firmware updates and signal adjustment.
Ideal Applications
Perfect for users who need:
Basic Wi-Fi coverage in a small home or office (email, browsing, HD streaming)
Expandable Wi-Fi reach via repeater or AP modes
Guest network setup or simple multiple device connectivity
Budget-friendly wireless access with flexible deployment options
Key Specifications
Wireless Standard: 2.4 GHz Wi‑Fi 4 (IEEE 802.11b/g/n), max 300 Mbps
Antenna: 2 × 5 dBi external high-gain, beamforming support
Ports: 1 × WAN, 3 × LAN (10/100 Mbps auto‑negotiation)
Power Supply: 9 V DC, 0.6–1 A adapter; max power ≤ 5.4 W
Weight & Dimensions: ~174.8 × 96.5 × 181.1 mm; net weight ~134 g
Operating Modes: Router; Repeater; Client+AP; WISP; Access Point
Security: WPA/WPA2-PSK; SSID hiding; guest network; QoS scheduling
Management: Web-based interface, system logs, firmware upgrade support
Operating Conditions: 0–40 °C, 10–90 % RH; Storage –40–70 °C, 5–90 %
Why Choose with Saruk Digital Solutions?
A budget-friendly solution for basic Wi‑Fi needs in smaller spaces.
Simple configuration, flexible operating modes, and secure guest network support.
Supports coverage enhancement via beamforming and amplified antennas.
Energy-efficient and compact desktop design, ideal for constrained setups.
