Product Overview
If you must have a fail-proof, zero-transfer-time power backup for mission-critical applications that require always-on power supply, the Mercury online UPS range will provide that solution at a price that's relatively friendly. The 6kva Mercury online UPS offers a rated capacity of 4200w which can support a sizable load of your sensitive office equipment. For network systems, servers, workstations and other IT equipment, the Mercury online UPS will provide the maximum power protection you require, delivering clean, stable pure sine wave power, with seamless power supply.
Stability
With its double conversion technology, the 6kva Mercury online UPS will not only ensure constant power supply to your critical equipment but will also isolate those sensitive applications from any power problem in the AC line.
Great Performance
This capacity of the Mercury Online UPS is relatively large enough to meet the requirements of many users. You should consider a higher capacity, if you load so requires or a lower one, all available on this website. The 6kva Mercury online inverter is powered by 20 x 12V/8.2Ah internal sealed, maintenance-free batteries to provide the power backup you need.
General Specifications
- Power6KVA / 4200W
- Voltage range176 ±5VAC~276 ±5VAC
- Frequency46~54Hz ±0.5Hz, or 56~64Hz ±0.5Hz auto sensing
- Input phaseSingle phase
- Power factor≥0.98
- Voltage range220VAC ±1%
- Output phaseSingle phase
- Frequency50Hz ±0.2% (battery mode)
- THD< 2% (Linear load); < 6% (non-Linear load)
- Overload105%~130% 10min turn to Bypass mode,
- > 130% 1s turn to Bypass mode
- Crest factor3:1 (max)
- WaveformPure sine wave
- Transfer time0ms (AC mode - Battery mode)
- 0ms (AC mode - Bypass mode)
- Efficiency≥88%
- AC mode5 cycles turn off inverter, no transfer to Bypass,
- provide alarm.
- Battery mode5 cycles turn off inverter, provide alarm.
- Bypass modeInput fuse blown or break action.
- Battery Model12V sealed lead acid maintenance free
- DC voltage240VDC
- Configuration20x 12V/8.2AH
- Backup time20min (half load) / 7min (full load)
- Charge current1A (standard unit) / 5A (long time unit)
- Recharge time90% capacity after 8hrs charging
- Communication InterfaceRS232; SNMP (optional)
- Parallel PortParallel availability for redundancy and load sharing up to three unit
- LCD IndicationInput voltage/frequency; battery voltage; output voltage/frequency; load watt/VA value & percent; inverter temperature; operation mode such as “on batt†or “on bypassâ€
- LED IndicationGreen: normal operation; Yellow: warning condition
- Red: abnormal operation
- Noise level≤ 55dB
- Temperature0~40ËšC; 0 ~ 40ËšC (storage temperature)
- Humidity0~95% (non-condensing)
- Altitude< 1500m
- Weight Net/Gross89/104kg (standard unit); 34/48kg (long time unit)
- Dimension (WxDxH)270 x 570 x 720mm
- Packaging (WxDxH)370 x 670 x 940mm
