Product Overview

The Z230 Small Form Factor Workstation from HP features a 3.3GHz Intel Core i5 processor along with 8GB of DDR3 RAM. It supports multitasking as well as provides the processing power to support a variety of multimedia and software applications. This Intel processor also comes equipped with NVIDIA NVS 310 Graphics to support enhanced multimedia functionality. Along with enhanced graphics support, you also benefit from integrated HD Realtek audio surround sound completing the multimedia experience. Saruk Digital Solutions has professional in-house technicians available for upgrades & installations on these workstations and laptops. Built with power and speed in mind, the Z Series is designed to enhance audio and video post-production workflows and more. Each HP Z series workstation or laptop features a range of top-tier processors and large RAM loadouts. The workstations are built with graphics flexibility in mind as well so that the end consumer can configure the graphics options to their needs, and each unit includes a three-year warranty.

Rock Solid Reliability

This workstation is designed for heavy workloads. It is capable of handling the demanding workloads of business applications. HP's extreme testing and validation processes ensure that the workstation delivers superior performance and reliability in any environment. The workstation has minimum environmental impact and lowers your total cost of ownership with a 92% efficient power supply and enhanced system reliability. This workstation has earned a wide range of ISV certifications to deliver better and smarter performance.

The Workstation that Fits Your Workspace

The redesigned workstation provides the capability and flexibility you demand in a 61% smaller form factor than the tower. Maintain impressive performance, greater storage capacity, more input/output ports, and greater flexibility while retaining the same small form factor size. Save time with easy data transfers. Accommodate more storage devices with four total drive bays, including a 2.5" HD bay for high-performance solid state drives. Boost the storage performance with RAID, solid state drives, or get the best of both worlds by combining large hard drives with an optional solid state drive as a cache device. Optimize this workstation for peak performance. The HP Performance Advisor helps you easily configure your system with suitable settings designed for specific applications.

Totally Immersive and Perfectly Productive

Power to spare and share. The Intel Xeon processors and rich graphics keep up with your work, thus increasing your productivity. Plug in and work on up to six displays. Enjoy superior performance and energy efficiency from Intel's next-generation processor architecture. This workstation allows you to choose between cost-effective integrated graphics and powerful 2D or 3D discrete graphics choices. With HP RGS (Remote Graphics Software) you can take your graphics intensive workstation applications wherever you go. Collaborate with colleagues around the office or around the world, in real-time.

Expansion slots

1 PCIe Gen3 x16 slot
1 PCIe Gen2 x4 slot /x16 connector
1 PCIe Gen2 x1 slot/x4 connector
1 PCIe Gen2 x1 slot

Expansion bays

1 external half height 5.25" bay
1 shared internal/external 3.5" bay.
1 internal 3.5" bay
1 internal 2.5" bay

Front I/O

2 USB 3.0, 2 USB 2.0, 1 Headphone, and 1 Microphone.

Internal I/O

1 USB 3.0 and 3 USB 2.0 ports available as 2 separate 2 x 10 (3.0 x1, 2.0 x1) and 2 x 5 (2.0 x2) header: supports one HP Internal USB 2.0 Port Kit and one USB 3.0 Media card reader.

Rear I/O

3 Displayport (DP 1.2) outputs from Intel HD graphics (available on specific processors only); 2 USB 3.0 ports, 4 USB 2.0 ports, 2 serial ports (1 standard, 1 optional), 1 parallel port (optional), 2 PS/2, RJ-45 (LoM), 1 audio Line-in, and 1 audio Line-out; 2 IEEE 1394b ports (optional).

Interfaces supported

14-in-1 Media Card Reader (optional)

Power supply

240 watts wide-ranging, active Power Factor Correction, 92% Efficient

Chipset

Intel C226 chipset

Memory

4 DIMM slots, supporting up to 32GB ECC/non-ECC, DDR3 1600 MHz

Graphics specifications

NVIDIA NVS 310 512MB Graphics

Form Factor

2.713 inches in height Ã— 6.150 inches in length

Graphics Controller

NVIDIA NVS 310

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 512MB DDR3
Clock: 875Mhz
Memory Bandwidth: 14GB/s

Connectors

2 x DisplayPort 1.2

Maximum Resolution

Up to 2560 x 1600 (digital display) per display.

Image Quality Features

The following video formats are supported:

MPEG2
MPEG4 Part 2 Advanced Simple Profile
H.264 SVC codec support
Support for 3D Blu Ray
VC1
DivX version 3.11 and later
MVC

Display Output

DisplayPort output:

Drives two DisplayPort enabled digital display at resolutions up to 2560 — 1600 at 60 Hz with reduced blanking, when connected natively using the 2 DisplayPort connectors on the NVS 310 graphics card
Supports 2 monitors up to resolution of 1920 — 1200 at 60 Hz with reduced blanking using DisplayPort 1.2 multi stream topology technology.

DVI-D output:

Drives two digital display at resolutions up to 1920 — 1200 at 60 Hz with reduced blanking using DisplayPort to DVI-D single-link cable adaptors
Drives two digital display at resolutions up to 2560— 1600 at 60 Hz with reduced blanking using DisplayPort to DVI-D dual-link cable adaptors

HDMI output:

NVS 310 is capable of driving two high definition (HD) panels up to resolutions of 1920 — 1080P at 60 Hz using DisplayPort to HDMI cable adaptors

VGA display output:

Drives two analog display at resolutions up to 1920 — 1200 at 60 Hz using DisplayPort to VGA cable adaptors

NVIDIA NVS 315 1GB Graphics (for HP Workstations)

Form Factor

2.713 inches in height Ã— 5.7 inches in length

Graphics Controller

NVIDIA NVS 315 (using GF119-825 GPU)
Number of Cores: 48 CUDA cores
Max. Power: 19.3W
Cooling Solution: Active fan heatsink

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 1GB DDR3
Clock: 875Mhz
Memory Bandwidth: 14GB/s

Connectors

DMS-59 output

Maximum Resolution

DMS-59 to VGA: 2048 x 1536 @ 85Hz
DMS-59 to DVI: 1980 x 1200 @ 60Hz
DMS-59 to DP: 2560 x 1600 @ 60Hz

Image Quality Features

MPEG2
MPEG4 Part 2 Advanced Simple Profile
H.264 SVC codec support
Support for 3D Blu Ray
VC1
DivX version 3.11 or later

Display Output

Up to 2 displays in the following configurations:

DisplayPort output:

Drives two DisplayPort enabled digital displays at resolutions up to 2560 Ã— 1600 at 60 Hz with reduced blanking, when connected via the DMS-59 to DP adapter.

DVI-D output:

Drives two digital display at resolutions up to 1920 Ã— 1200 at 60 Hz with reduced blanking using DMS-59 to DVI-D single-link cable adaptor

VGA display output:

Drives two analog display at resolutions up to 2048 Ã— 1536 at 85 Hz using DMS-59 to VGA cable adaptor.

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.3

General Specifications

Intel Corei5 4590 3.30GHz

8GB DDR4 SDRAM

1000GB HDD

NVIDIA NVS 310 Graphics

One Year Warranty
